Characteristics
  |
Used for media: gas, liquids |
 |
Resistant to hydrolysis |
 |
Good chemical resistance |
 |
Temperature resistance: from -10 ÷ +50°C |
 |
Pressure resistant |
 |
Flexibility- ★★★☆☆ |
 |
Package length: 20 m (our eshop system offer you option 1m. It means 1pc od coil 20m. Sorry for trouble) |
Technical parameters
| Application |
- liquid and gaseous substances - suitable for irrigation - can also be used as a pressure hose |
| Wall material | softed phthalate-free PVC (transparent) with PES net |
Parameters of all produced diameters
| Product catalog | Inner diameter [mm] |
Approx. weight [kg/m] |
Working pressure [bar] |
| WO 1/2 | 1/2" (12,5 mm) | 4 / per coil | 20 |
| WO 5/8 | 5/8" (16 mm) | 5 / per coil | 20 |
| WO 3/4 | 3/4" (19 mm) | 6 / per coil | 10 |
| WO 1/1 | 1" (25 mm) | 7 / per coil | 10 |
The tolerance for all parameters is maximum 5%. All parameters apply to room temperature (approx. 22°C). The length of hose in one coil is 20m.
