Suction hoses PVC Asen

Suction hoses PVC Asen

Product rating: Not rated yet. Be first!

Your rating:

Liquids Solid Gas

PVC hoses suitable for sewage machines, agricultural machinery with wall thickness 2,4. Reinforced with a metal spiral, often used for suction of sludge, faeces, organic waste, abrasive particles from cesspools, septic tanks, etc. The hoses are also suitable for pressure pumps or other applications where there are high pressure requirements. due to their solid solid construction they are not very flexible. They may break if the permitted bending radius is exceeded.

29,03 € incl. VAT

29,03 € incl. VAT / m

Availability: Shipping in 2-5 days

Producer: RONDO

Characteristics

picto - airsolidliquids

Used for media: gas, solid, liquids

RESISTANT TO HYDROLISYS

Resistant to hydrolysis

chemical resistant

Good chemical resistance

Table of chemical resistance HERE

flammability class Flammability class V-I acc. to UL94
temperature resistance Temperature resistance: -5 ÷ +70°C
smooth inside Smoothed inner wall
flexibility Flexibility ★★☆☆☆
lenght

Production length: 10m

Packing system for standard e-shop orders:

DN 75÷110mm - 1pc = up to 10m (for longer than 10m units, contact us for a special transport offer)

DN 111÷400mm - 1pc = up to 2m (for longer than 2m units, contact us for a special transport offer)

Example: if ordered 12m of DN 100mm and 2m of DN 300mm - standardly you recieve 10m+2m of DN 100mm and 2m of DN 300mm. If you need different lenghts (for example 6+6m DN 100mm and 1+1m DN 300mm) note it in the order notes.

Note! When ordering a quantity other than the production lengths, it is not possible to return the goods.

Profile of kecalo hoses



Technical parameters

Application

for sewage machines, agricultural machinery

for suction of sludge, faeces, organic waste, abrasive particles from cesspools, septic tanks, etc

for street cleaning machines, road cleaning vehicles, vacuum cleaners for leaves, etc.

for ventilation and dedusting systems

use in static or very mild dynamic operation

Wall material softed phthalate-free PVC (transparent)
Wall thickness 2,1÷2,4 mm between spirals
Instructions for using hoses

HERE

Parameters of all produced diameters

Product catalog Inner
diameter
[mm]
Outer
diameter
[mm]
Bending
radius
[mm]
Approx.
weight
[kg/m]
Pressure
[bar]
Vacuum
[bar]
2 - 07 - 0075 75 85 330 1,8 2,3 -0,90
2 - 07 - 0082 82 92 440 2,0 2,1 -0,90
2 - 07 - 0090 90 100 460 2,2 2,0 -0,90
2 - 07 - 0100 100 110 490 2,3 1,8 -0,90
2 - 07 - 0110 110 120 660 2,5 1,7 -0,90
2 - 07 - 0115 115 125 680 2,6 1,6 -0,85
2 - 07 - 0120 120 130 700 2,7 1,6 -0,85
2 - 07 - 0125 125 135 730 2,9 1,5 -0,80
2 - 07 - 0127 127 137 790 2,9 1,5 -0,70
2 - 07 - 0130 130 140 830 3,0 1,4 -0,60
2 - 07 - 0135 135 145 840 3,1 1,4 -0,60
2 - 07 - 0140 140 150 860 3,2 1,3 -0,60
2 - 07 - 0150 150 160 890 3,4 1,5 -0,80
2 - 07 - 0160 160 170 950 4,1 1,4 -0,80
2 - 07 - 0170 170 180 980 4,4 1,3 -0,70
2 - 07 - 0180 180 190 1120 4,8 1,3 -0,60
2 - 07 - 0190 190 200 1190 5,1 1,2 -0,50
2 - 07 - 0200 200 210 1250 5,5 1,1 -0,50
2 - 07 - 0210 210 220 1470 5,8 1,0 -0,40
2 - 07 - 0220 220 230 1760 6,1 1,0 -0,40
2 - 07 - 0240 240 250 1920 6,4 0,8 -0,35
2 - 07 - 0250 250 260 2000 6,6 0,8 -0,35
2 - 07 - 0280 280 290 2520 6,9 0,7 -0,35
2 - 07 - 0300 300 310 2700 7,3 0,7 -0,35
2 - 07 - 0315 315 325 2835 7,5 0,7 -0,35
2 - 07 - 0350 350 360 3500 8,2 0,6 -0,35
2 - 07 - 0400 400 410 4000 8,8 0,5 -0,35

The tolerance for all parameters is 5%. All parameters apply to room temperature (approx. 22°C). It is possible to produce a hose of non-standard diameter, in the required color or with your own print on special order. The commercial lengths of the hoses are measured in the maximum expanded state. Ground the spiral to discharge static electricity. The flow direction is indicated by an arrow on the hose.
